Stone Bridge Polishing Machine Description
Stone bridge polishing machine is a bridge design polisher equipment to polishing marble, granite, quartz and other stone materials. There are some stone factories using automatic continuous polishing machine to make the polish, the main polish heads would be four claws or six claws polishing head, these kind of polishing head is very expensive, the price would be more than 1000USD each set. and the dimension of head is very big so the machine dimension would be big,in this case the price of polishing machine is very high, some factories can’t afford to buy it. Nowadays, more and more factories are using bridge polishing machine as their option, there are many kinds of bridge type polisher equipment, some are with single head bridge polishing machine and some are multi-heads. This machine greatly improves the production efficiency, reduces the labor cost and reduces the labor intensity. Compare with continuous automatic polishing machine, price of this bridge polishing machine is very cheap and high working efficiency. Normally, the output of a multi-heads bridge polishing machine is about 15-20 sqm per hour. There are also some weakness on this bridge polishing machine, such as difficult to replace polishing disc and the polishing speed is lower than automatic ones.
Stone Bridge Polishing Machine Details
Stone Bridge Polishing Machine Specifications
Item Name | Unit | Value |
Power of main motor | KW | 11 |
Polishing efficiency | Sqm per hour | 4 |
Max Polishing size | mm | L*W*H=2500*1200*100 |
Water consumption | M3/min | 0.15-0.3 |
Machine weight | KG | 2000 |
Overall size | mm | L*W*H=5500*2200*1800 |
